Horizontal screw with mixing machine suitable for: application in pesticides, veterinary medicine, food, chemicals, biotechnology, aquaculture, ceramics, refractory material, plastic, composite fertilizer solid solid (i.e. powder and powder) solid slurry (i.e., the mixed powder and glue liquid), is especially suitable for viscous material mixed.

Working principle of horizontal spiral ribbon mixer:

Horizontal screw with mixing machine is composed of a mixing chamber, an agitator, a driving device basic composition, U type tubular chamber mounted double-layer differential to ribbon coiled stirrer shaft, outer spiral with power driven, the coiled form with the direction of rotation the material from both ends of the U-shaped positions to the center of the drive, and inner spiral with the material from the middle to both ends of the drive, forming mixed convection.

Mixer horizontal cylinder at the bottom of the central open mouth, spindle rotating direction of the drive cylinder inner wall material to the central a material discharging mouth with outer spiral volute structure complex, to ensure that cylinder body of the material discharging no dead ends.
